| Ports GB Combo Uplinks |
4 |
| Ports FE PoE RJ45 |
4 (10/100Mbps) |
| Ports FE RJ45 |
4 (10/100Mbps) |
| Dimensions |
155.4 x 155.4 x 129.2 mm |
| Poids |
2.88kg |
| Administrable |
Oui |
| Switch couche 2 |
IEEE 802.1, 802.3, 802.3at, 802.3af standard, VTPv2, NTP, UDLD, CDP, LLDP, Unicast Mac filter, Flexlink, Resilient Ethernet Protocol (REP), VTPv3, EtherChannel, Voice VLAN, QinQ tunneling, Industrial macro configuration |
| Sécurité |
SCP, SSH, SNMPv3, TACACS+, RADIUS Server/Client, MAC Address Notification, BPDU Guard, Port-Security, Private VLAN, DHCP Snooping, Dynamic ARP inspection, IP Source Guard, 802.1x, Guest VLAN, MAC Authentication Bypass, 802.1x Multi-Domain Authentication, Storm Control, Trust Boundary, FIPS 140-2, ACT2, Secure boot, Full flexible Netflow |
| Multicaste couche 2 |
IGMPv1, v2, v3 Snooping, IGMP filtering, IGMP Querier |
| Administration et management |
Fast Boot, Express setup, Web Device Manager, Industrial Network Director (IND), MIB, Smartport, SNMP, syslog, storm control, unicast, multicast, broadcast, SPAN sessions, RSPAN, DHCP server, customized DOM (digital optical management), Embedded Event Manager (EEM), Plug-n-Play Agent, Port-based DHCP |
| Ethernet industriel |
CIP Ethernet/IP, Profinet v2, IEEE 1588 PTP v2, NTP to PTP translation, CIP Time Sync |
| Qualité de service |
Ingress Policing, Rate-Limit, Egress Queueing/shaping, AutoQoS, QoS, PROFINET QoS |
| Couche 2 IPv6 |
IPv6 Host support, HTTP over IPv6, SNMP over IPv6 |
| Routing |
IPv4 Static Routing |
| Gestion industrielle |
Layer 2 switching with 1 sur 1 static Network Address Translation (NAT) |
| Redondance prévue |
Redundancy Ethernet Protocol ring (REP), Parallel Redundancy Protocol (PRP), Media Redundancy Protocol (MRP) ring, MRP Auto Manager (MAM), High Availability Seamless Redundancy (HSR), PTP over HSR, HSR-PRP (Dual RedBox mode), HSR-HSR (Quadbox) |
| Utilitaires |
Power Profile 2011 and 2017, dying gasp, GOOSE messaging, SCADA protocol classification, MODBUS TCP/IP, utility SmartPort macro, BFD, Ethernet OAM, IEEE 802.3ah, CFM (IEEE 802.1ag) |
| Nombre de ports ethernet |
12 ports |
| Ports SFP |
4 ports |
| Manageable ? |
Manageable |
| Débit |
10/100/1000Mbps, 10/100Mbps |
| Température extrême |
Oui
|
| PoE |
Oui
|
| Fibre optique |
Mono-mode, Multi-mode |
| SKU |
IE-4000-4T4P4G-E |
| Marque |
CISCO
|
