| Technologie mémoire vive |
DDR3L 1066 MHz |
| Capacité maximum RAM |
8 GB |
| Socket |
1 x 204-pin SO-DIMM |
| Processeur |
Intel Atom E3825 DC SoC |
| Cache L2 |
1 MB |
| BIOS |
AMI EFI 64 Mbit |
| Fréquence |
1.33 GHz |
| Nombre de coeur |
2 |
| mSATA |
Laverage MiniPCIe #1 slot |
| Baie disque 2.5" |
1 x removable 2.5" drive bay (Max 9.5mm height) |
| Température en fonctionnement |
With extended temp. peripherals: -30 ~ 65 °C (-22 ~ 158F) with 0.7 m/s air flow, With 2.5 inch hard disk: 0 ~ 40 °C (32 ~ 104 °F) with 0.7 m/s air flow |
| Température max. en fonctionnement |
With extended temperature peripherals: -30 ~ 60° C with 0.7m/s air flow (standard) -40 ~ 70° C with 0.7m/s air flow (by project), With standard temperature peripherals: 0 ~ 45° C with 0.7m/s air flow |
| Watchdog Timer |
255 levels timer interval, setup by software |
| Power Type |
AT/ATX |
| Alimentation |
9 ~ 36 VDC w/isolation |
| Power Ignition Management |
Selectable boot-up & shut-down voltage, on/off delay time |
| Isolation |
1.5KV Isolated |
| Ethernet LAN 1 |
10/100/1000 Mbps Intel I210-IT GbE, support Wake on LAN |
| Ethernet LAN 2 |
10/100/1000 Mbps Intel I210-IT GbE, support Wake on LAN |
| Chipset |
Intel Gen7 Graphics |
| Graphique |
DirectX11, OpenGL3.2, OpenCL1.1 Full HW acceleration, decode: H.264, MPEG2/4, VC-1, WMV9. Encode: H.264, MPEG2 |
| HDMI |
Lockable HDMI connector, up to 1080p |
| VGA |
Up to 2560 x 1600 @ 60Hz |
| Main System |
Realtek ALC888S, High Definition Audio (HD), Line-in, Line out, Mic-in |
| USB |
3 x USB 2.0 & 1 x USB3.0 |
| Port série |
2 x RS-232/422/485 ports (support auto flow control, BIOS selectable) |
| GPIO |
6 x DI & 2 x DO w/ 3KV isolation Input Voltage: 0 to 30 VDC, Output Current: Max. 500 mA per channel On-state Voltage: 24 VDC nominal, open collector to 30 VDC |
| Power over Ethernet, PoE |
N/A |
| Optional COM or CANBus |
2 x DB9 connectors for RS-232/422/485 signal (Default) or CANBus 2.0A/B (Module option) |
| Humidité |
95% @ 40° C (non-condensing) |
| Mini PCIe #1 |
Full-size Mini PCIe, support mSATA |
| Mini PCIe #2 |
Half-size Mini PCIe, support WLAN module |
| Mini PCIe #3 |
Full-size Mini PCIe w/SIM holders, support WWAN module. (USB interface) |
| Mini PCIe #4 |
Full-size Mini PCIe w/SIM holders, support WWAN module. (USB interface) |
| Châssis |
Aluminum housing, Silver |
| Montage |
Din-Rail mounting, Desk/wall-mounting, VESA mounting |
| Dimensions |
264.5 x 69.2 x 133.0 mm |
| Système Windows |
WES8, WES7, Windows 8, Windows 7 |
| Linux |
Support by project |
| EMC |
CE/FCC Class A, CCC, BSMI |
| Sécurité |
UL, CCC, BSMI, E-Mark (E13) |
| In-Vehicle Power |
ISO7637-2 Lev.4 |
| Vibration/Shock |
| With mSATA/SSD |
IEC 60721-3-5 Class 5M3 |
| SKU |
ARK-2121V-S3A2E |
| Marque |
Advantech
|
Configurés et assemblés en France
