PPC-310S-PN9A Fanless Panel PC 10.4" with Intel N97 IP66 true-flat

The PPC-310S-PN9A from Advantech is suitable for implementing an operator interface on a production machine, assembly line, or control station.

Its touchscreen allows displaying operating parameters, viewing alarms, and entering production data, depending on the installed software.

Its two 2.5 Gb/s Ethernet ports allow the terminal to connect to the machine network and the workshop network, while its two RS-232/422/485 ports facilitate communication with serial equipment. Application protocols depend on the deployed software and drivers.

Features:

• True-flat touchscreen with industrial-quality LCD panel
• High-performance Quad-Core Intel N97 processor, fanless
• Front panel rated IP66 for water and dust resistance
• Supports two displays with 1 x external DP
• 2 x 2500BASE-T Ethernet ports with TSN technology
• 1 x M.2 M Key 2280 for storage (SATA or NVMe PCIe x1)
• Supports TPM2.0 hardware security

This panel PC offers 2 x RS-232/422/485, 2 x USB 3.2, and 2 x USB 2.0 for complete connectivity. The power input is 24 VDC ±30%, with a consumption of 36 W @ 24 VDC. Certified by CE, FCC Class B, BSMI, CB, UL, CCC, UKCA, and VCCI, it operates optimally at temperatures ranging from -10 to 50°C.
