| Communications Standards |
IEEE 802.3, 802.3u, 802.3x, 802.3z, 802.1D, 802.1w, 802.1p, 802.1Q, 802.1X, 802.3ad, 802.3ab |
| LAN Interfaces |
24 x RJ45 (Gigabit Copper) |
| Combo Ports |
4 x RJ45/SFP (mini-GBIC) combo ports |
| Standards |
10/100/1000Base-T (X), Optional 100Base-FX, 1000Base-SX/LX/LHX/XD/ZX/EZX |
| Transmission Distance - Ethernet |
Up to 100 m (4-wire Cat.5e, Cat.6 RJ45 cable suggested for Gigabit port) |
| Transmission Distance - SFP |
Up to 110 km (depends on SFP) |
| Transmission Speed - Gigabit Copper |
10/100/1000 Mbps, Auto-Negotiation |
| Transmission Speed - Gigabit Fiber |
Up to 1000 Mbps |
| Interface Connectors Ethernet Connectors |
24 x RJ45 (Ethernet) |
| Combo Ports |
4 x RJ45/SFP (mini-GBIC) combo ports |
| Power |
4-pin removable screw terminal (Power) |
| Relay |
3-pin removable screw terminal (Relay) |
| Console |
RS-232 (RJ45) |
| LED Indicators 10/100T (X) |
Link/Activity, Duplex/Collision |
| Gigabit Copper |
Link/Activity, Speed (1000 Mbps) |
| SFP |
Link/Activity |
| Switching Capacity |
56 Gbps |
| Forwarding Rate |
41.6 Mpps |
| MAC Address |
8K |
| Jumbo Frame |
9K |
| Packet Buffer |
4.1 Mbit |
| Network Management Configuration |
Web browser, Telnet, Serial console, TFTP, SNMPv1/v2c/v3, Port Speed/Duplex Configuration, IPv6 |
| VLAN |
IEEE 802.1Q, GVRP, Port-based VLAN |
| VLAN Group |
256 (VLAN ID 1 ~ 4094) |
| Redundancy |
Advantech X-Ring, 802.1w/1D/1s RSTP/STP/MSTP |
| Security |
IP Security, SSH, SSL, SNMPV3, HTTPS, IP Source Guard, DHCP Snooping, ARP Spoofing Prevention, 802.1X, TACACS+, Access Control List |
| Traffic Control |
IGMP Snooping/Query for multicast group management, Port Trunking, Static/802.3ad, LACP Rate limit and storm control, IEEE 802.1p QoS CoS/TOS/DSCP priority queuing, IEEE 802.3x flow control |
| Diagnostics |
Port Mirroring, Real-time traffic statistic, MAC Address Table, SNTP, Syslog, E-Mail Alert, SNMP Trap, RMON |
| Power Power Consumption |
20W @ 24V |
| Power Input |
12-48 VDC |
| Fault Output |
2 Relay Outputs |
| Protection - Power Reverse |
Present |
| Protection - Overload Current |
Present |
| Mechanical Enclosure |
IP30, metal shell with solid mounting kits |
| Dimensions (W x H x D) |
438 x 43.6 x 259.20 mm (17.24" x 1.72" x 10.2") |
| Mounting |
1U 19" Rack mount |
| Environmental Operating Temperature |
-40 ~ 70°C (-40 ~ 158°F) |
| Storage Temperature |
-40 ~ 85°C (-40 ~ 185°F) |
| Operating Humidity |
10 ~ 95% (non-condensing) |
| Storage Humidity |
10 ~ 95% (non-condensing) |
| Certifications & Compliance Safety |
UL 61010-2-201 |
| EMI |
CE FCC EN55022 Class A |
| EMS |
EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8 |
| Shock |
IEC 60068-2-27 |
| Freefall |
IEC 60068-2-32 |
| Vibration |
IEC 60068-2-6 |
| Railway Track Side |
EN 50121-4 |
| Cybersecurity |
IEC 62443-4-1 & IEC 62443-4-2 |
| RoHS |
2002/95/EC Compliant |
| Reliability MTBF |
787,940 hours |
| Typical Applications |
Edge to core industrial networks |
| Caveats |
This model does not provide per-port PoE power output. |
| Size |
400x590x160mm
|
| Weight |
5470g |
| SKU |
EKI-7428G-4CI-BE |
| Brand |
ADVANTECH
|
