| Processor Family |
Intel 12th/13th/14th Generation Core i, Pentium, Celeron (LGA1700 socket) |
| Chipset |
Intel H610E |
| BIOS |
AMI 256Mb SPI Flash |
| CPU Options (12th Gen) |
i9-12900(E), i7-12700(E), i5-12500(E), i3-12100(E), Pentium G7400E, Celeron G6900E, i9-12900TE, i7-12700TE, i5-12500TE, i3-12100TE, Pentium G7400TE, Celeron G6900TE |
| CPU Options (13th Gen) |
i9-13900(E), i7-13700(E), i5-13500(E), i5-13400(E), i3-13100(E), i9-13900TE, i7-13700T(E), i5-13500T(E), i3-13100T(E) |
| CPU Options (14th Gen) |
i9-14900, i7-14700, i5-14500, i5-14400, i5-14400F, i3-14100, i9-14900T, i7-14700T, i5-14500T, i5-14400T, i3-14100T |
| Memory Technology |
Dual-channel DDR5 4800 MHz |
| Memory Socket |
2 x 262-pin DDR5 SODIMM (up to 64GB per socket) |
| Memory Maximum Capacity |
128GB |
| HDD/SSD |
1 x 2.5" HDD/SSD (up to 2 x 2.5" SSD by optional kit; 2 x 3.5" HDD by i-Module) |
| mSATA |
1 |
| NVMe M.2 |
Not supported in H610E SKU |
| RAID |
Not supported in H610E SKU |
| Graphics Chipset |
Core i: Intel UHD Graphics 770; Pentium/Celeron: Intel HD Graphics 710 |
| VGA |
1 x DB15, up to 1920 x 1200 maximum resolution |
| HDMI |
1 x HDMI, up to 4096 x 2160@30Hz |
| Ethernet Controller |
H610E LAN1: Intel I219V, LAN2: Intel i210IT |
| Ethernet Interface |
2 x RJ45 |
| USB 3.2 (Gen2) |
0 |
| USB 3.2 (Gen1) |
4 |
| USB 2.0 |
4 |
| RS-232/422/485 |
2 x DB9 with auto flow control (optional 4 x additional RS-232 available) |
| Total Serial Ports |
2, up to 6 (Optional) |
| Audio Channels |
2 (1 x line out and 1 x mic in) |
| PCIe slot |
Supports Advantech MIC-75 series i-module |
| Mini PCIe/mSATA |
1 x mini PCIe, 1 x mSATA |
| LED |
2 (1 x Storage and 1 x Power), 4 for COM1 TX/RX and COM2 TX/RX |
| Button |
1 x Power on/off switch |
| Remote Switch |
Yes, 2pin terminal block (Optional) |
| Watchdog Timer Output |
System reset |
| Watchdog Timer Interval |
Programmable 1 ~ 255 sec/min |
| TPM |
Supports Intel TPM technologies |
| vPro/AMT |
Supports Intel vPro/AMT technologies |
| Power Input Type |
ATX/AT |
| Input Voltage Range |
9 ~ 36 VDC |
| Power Consumption (Typical) |
45.7W |
| Power Consumption (Maximum) |
108W |
| Dimensions (Extreme) |
107.3 x 192 x 230 mm (4.22" x 7.55" x 9.05") |
| Weight (Extreme) |
4.5 kg (9.92 lbs) |
| Installation |
Desktop/wall mount |
| Operating Temperature (Extreme with air flow) |
-20 ~ 70 °C with 0.7 m/s air flow |
| Operating Temperature (Extreme without air flow) |
-20 ~ 50 °C without air flow |
| Storage Temperature |
-40 ~ 85 °C |
| Operating Humidity |
95% @ 40 °C (non-condensing) |
| Vibration (with SSD) |
3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis |
| Vibration (with 2.5" HDD) |
1 Grms @ 5 ~ 500 Hz, random, 1 hr/axis |
| Shock (with SSD) |
20G, IEC-68-2-27, half-sine wave, 11 ms duration |
| Shock (general) |
50G 11 ms |
| EMC |
CE/FCC Class A, CCC, BSMI |
| Safety |
CB/UL, CCC, BSMI |
| Operating Systems |
Windows 11, Windows 10, Windows 10 IoT, Linux OS |
| Remote Management |
Advantech iBMC 1.2 remote out-of-band power management sol |
| Multiple Display |
| H610E |
3 x independent displays (third display output via optional cable) |
| Operating System |
Linux, Windows, Windows 10 IoT |
| Features |
Ethernet RJ45, HDMI, USB port, Serial Port, VGA |
| CPU |
Intel i3, Intel i5, Intel i7, Intel i9, Pentium / Celeron / ATOM |
| Mount options |
Table, Wall mount |
| IP |
IP40 |
| Design |
Fanless |
| Interface de communication |
Ethernet, Serial, USB |
| Ethernet ports count |
2 ports |
| Extreme temp |
Yes
|
| Serial port |
2 |
| SKU |
MIC-770V3H-E0A1 |
| Brand |
ADVANTECH
|
