15" XGA TFT LCD with resistive (default) or projected capacitive (by request) touchscreen Intel® Atom™ x6425E quad-core, 2.0 GHz processor Fanless, slim design Supports 1 x 2.5" SATA and 1 x M.2 B key slot for expansion 1 x PCI/PCIe x1 expansion slot Wide operating temperature range (-20 ~ 60 °C/-4 ~ 140 °F) Wide range DC support (9 ~ 32 VDC) 1 x isolated RS-422/485 with automatic flow control Dual 2.5GBASE-T Ethernet supports Time-Sensitive Network (TSN) technology Optional GPIO (8 channels, TTL level)
| Characteristic |
Value |
| Size |
15" |
| Operating System |
Windows 10 IoT, Windows 11 |
| Features |
Display Port, Ethernet RJ45, HDMI, USB port, Serial Port |
| CPU |
Pentium / Celeron / ATOM |
| Mount options |
Panel mount, Wall mount |
| IP |
Front IP66 |
| Design |
Fanless |
| Touch |
Resistive |
| Interface de communication |
Ethernet, GPIO, Serial, USB |
| Ethernet ports count |
2 ports |
| Extreme temp |
Yes
|
| Serial port |
5 |
| SKU |
PPC-415 |
| Brand |
ADVANTECH
|
